Product line 09
Standard PCB
Double-sided and 4 to 6 layer FR-4, the workhorse of the catalogue. Fixed process windows, 100% electrical test and quick turns on repeat orders — the tenth lot matches the first.
2 – 6Layers
5 – 7 dLead time
100%Electrical test
HASLSurface finish
Catalogue
Boards we build on this line.
Representative items from this line’s catalogue. Open a board for its build parameters — every card leads to its own detail page.
6-Layer Control Board
6L · S1141, S1000, 370HR · Immersion Gold/OSP
View this board
BGA Assembly Board
multilayer · 4mil / 4mil · Immersion Gold
View this board4-Layer General Purpose PCB
4L · 0.3-6.0mm · 0.5OZ - 6OZ
View this boardMultilayer Fast-Turn Board
2L · ENIG,HASL,OSP · 0.15-6.0mm
View this boardAndroid Motherboard PCB
6L · 1.0 mm · ENIG
View this board4-Layer Automotive Control PCB
4L · Shengyi FR4 · Immersion Gold
View this boardTechnical specifications
Standard PCB
| Layers | 2 – 6 |
| Board thickness | 0.8 – 2.0 mm |
| Copper weight | 1 – 2 oz |
| Min trace / space | 6 / 6 mil |
| Min drill | 0.30 mm |
| Where it is used | Industrial · Consumer · Instruments |
Other product families
No obligation
Send the file. Get a real answer.
Upload a Gerber and we will come back within 24 hours with the DFM issues, a price and a lead time. If your design is not a fit for our process, we will say so.
